Dipstick Level Gauge

Name: Dipstick Level Gauge
Brand: D. B. INSTRUMENTS & CONTROLS
Price: 10000 INR
Availability: InStock

Price 10000 INR/ Unit

Get a Price/Quote

MOQ : 5 Units

Dipstick Level Gauge Specification

Case
Stainless Steel

Thread
G1/2 or as per request

Frequency
N/A (Manual operation)

Measuring Range
Up to 3000 mm (customizable)

Outer Size
Approx. 20 mm width

Sensor Type
Manual Measurement

Display
Mechanical Dip Reading

Usage
Industrial

Material
Stainless Steel 304 / 316

Working Presssure
Atmospheric

Product Type
Dipstick Level Gauge

Seal Material
Viton / NBR / PTFE

Grade
Industrial Grade

Color
Gray

Application
Level Measurement in Tanks, Oil Tanks, Liquids

Accuracy
2 mm

About Dipstick Level Gauge

Stainless steel made Dipstick level Gauge is a rod shaped instrument used for measuring the depth of liquid. Suitable for top or side installation purpose, this instrument can maintain up to 2000 mm measurement range. This level gauge is equipped with float submerged in non magnetic substance and specially developed chamber. The magnetic system of its float enables it to ride on specific liquid level. External visual indicator is also provided with this level gauge. Offered Dipstick level Gauge is useful for measuring oil level of automobile engine. It is offered with accessories like transmitter and level switch. Long life span and user friendly design are their key aspects.

Product details

Maximum working pressure	10 kg/sq.cm
Maximum Working Temperature	100 deg C
Window Material	Crystal Clear Acrylic
Country of Origin	Made in India
Material	Stainless Steel 304 / 316
Brand	D B Instruments

Industrial Durability and Precision

Constructed from stainless steel 304 or 316, this dipstick level gauge provides outstanding resilience against challenging industrial environments. It features a mechanical dip reading, delivering 2 mm accuracy for precise manual liquid level measurement in tanks, oil reservoirs, and various industrial liquids.

Customizable Solutions for Unique Needs

Catering to a wide range of industrial setups, the gauge offers customization in rod length, diameter, and material. Choose from threaded or flanged end fittings and select compatible seals for your specific application, making this gauge versatile for both standard and specialized industrial tanks.

Easy Monitoring and Maintenance

This mechanically operated level gauge requires no electrical supply, making it straightforward to use and maintain. Its robust design, clear display, and atmospheric working pressure adaptability simplify monitoring, even in environments with fluctuating temperatures or demanding conditions.

FAQs of Dipstick Level Gauge:

Q: How does the dipstick level gauge measure liquid levels?

A: The dipstick level gauge uses a manual measurement process, where the rod is inserted into the tank, and the liquid level is read directly from the mechanical dip indicator. This system does not require power supply and provides highly reliable measurements for industrial applications.

Q: What customization options are available for the gauge?

A: Both the rod diameter (6 mm, 8 mm, or custom), measuring length (up to 3000 mm), material (SS 304 or 316), end fitting (threaded or flanged), seal material (Viton, NBR, PTFE), and thread type (G1/2 or customized) can be tailored to fit your specific tank or process requirements.

Q: Where can this level gauge be installed?

A: Designed for industrial use, the dipstick level gauge is suitable for top mounting on tanks, oil reservoirs, and containers that store a variety of liquids. Its robust construction and weather-resistant IP55 protection allow installation in both indoor and outdoor industrial environments.

Q: What are the benefits of a manual measurement sensor type?

A: Manual measurement provides intrinsic safety, eliminates the need for electrical supply, reduces potential points of failure, and allows direct visual verification, which is especially useful in hazardous or remote settings where reliability and simplicity are critical.

Q: When should this dipstick gauge be used over other level measurement devices?

A: This gauge is ideal when you require a low-maintenance, cost-effective, and accurate solution for periodic or routine level checks, particularly in locations where electrical or electronic sensors are impractical or not allowed due to safety regulations.

Q: What is the process for installing the dipstick level gauge?

A: The gauge is installed using the top-mounted threaded or flanged connection according to tank specifications. Once secured, it is ready for immediate manual use, and the seal material ensures leakage prevention at the mounting joint.
